Magnetic measurement system integrator
Magnetic measurement system integrator
1.Magnetic measurement is the most basic diagnostic system on the HH70 device and an important diagnostic system for device operation and plasma physics research；
2.Equipped with pre triggered state detection and calibration, triggering integration; The integration time can be automatically measured and uploaded onboard；
3.Can automatically calibrate the zero point for closed-loop compensation [when the integrator is in discharge state]；
4.It can measure the change in voltage within the integration state and upload it without the need for the acquisition card function；
5.Equipped with self checking functions such as overcurrent, overvoltage, abnormal integration, and signal quality troubleshooting
_______________________________________________________________________________________________________________________________________________________________
1.Integral time: 0.5mS 1ms 2ms 5mS 10mS 20mS 50mS optional;；
2.Integral drift: typical value<5mV/20S；
3.Digital compensation integral drift: typical value<5mV/100S；
4.Communication function: Receive pre trigger, trigger, and integration duration signals from the central control；
5.Integral RC accuracy: Integral resistance R stability ± 0.01%, integral capacitance C stability ± 0.1%, RC stability within 0.1%；
6.Impedance: Input impedance greater than 100k Ω, output impedance less than 100 Ω。
