3G Variable Frequency Partial Discharge Receiver
3G Variable Frequency Partial Discharge Receiver
1.Partial discharge instrument is a specialized instrument for measuring and analyzing the insulation performance of power equipment;
2.Adopting modern electronic and computer integrated technology to achieve signal amplification (analog, electronic, digital), filtering, data acquisition, data processing, graphic display, and automatic generation of test reports;
3.Scope of application, detection method, and test circuit of partial discharge instrument;
4.The partial discharge detection system is a 2-channel, desktop, TFT LCD display, which is reliable and has a low failure rate;
_______________________________________________________________________________________________________________________________________________________________
1.Sampling rate: up to 10M;
2.Sampling accuracy: 12 bits;
3.Measurement frequency band: 3dB bandwidth 10kHz~1MHz;
4.Digital filtering: Choose freely between 10kHz and 1MHz;
6.The capacitance range of the testable product is 6pF to 250 μ F;
5.Power mode: AC 220V； Frequency 50Hz; Power 300W;
